Why Stotko 316 Stainless Steel Cable Clamps?
- ✔ Marine-grade 316 Stainless Steel for superior corrosion resistance in wet, acidic and salty conditions
- ✔ Self-tightening two-component design with integrated safety sling
- ✔ Custom diameters from 10 mm to 100 mm+
- ✔ Quick release and fully reusable – dramatically reduces long-term costs
- ✔ Proven performance in South African deep-level mining shafts
- ✔ ISO 9001 certified with full test certificates available
- ✔ Manufactured locally in Johannesburg since 1973
- ✔ Fast lead times and technical support
Key Applications
Technical Specifications
| Material | 316 Stainless Steel |
| Cable Diameter Range | 10 mm – 100 mm (custom available) |
| Design | Self-tightening, two-piece with safety sling |
| Compression Strength | Up to 71 kN (tested) |
| Standards | ISO 9001 Compliant |
Why We Make a 316 Stainless Steel Version
The 316 stainless range is an ultra-thin-body version of the SK clamp, not a replacement for it. SG 42 cast iron with ArmorGalv® Sherardising remains the workhorse for South African shaft work: high load capacity, CSIR-tested sizes, and a metallurgically bonded zinc-iron coating that belongs on the casting. That is the correct spec for most underground installations.
316 stainless exists for a different job. Because the material itself carries the corrosion resistance, the body can be made far thinner than cast iron. That cuts mass and packed volume, which makes export freight materially cheaper. The trade-off is a higher unit investment: you pay more per clamp, but spend less getting a crate across a border.
Buyers also get the inherent 316 benefits: no coating to maintain in wet, acidic, salty or chemical duty, and a clean specification for marine, coastal, plant and export contracts that call for stainless rather than coated iron.
Choose by duty, not by fashion:
- ✓ High load, local shaft, standard bunton fit: Sherardised SK cast iron
- ✓ Thin profile, international shipment, or a stainless specification: 316 stainless SK11 / SK21 / SK31 (larger diameters on request)
Body dimensions differ from the cast-iron SK range. Confirm width, jaw depth, bracket slot and bolt size with us before you match an existing bracket.
Available Sizes: 316 Stainless Steel Range
An ultra-thin-body version of our standard SK clamp, in marine-grade 316 stainless steel instead of Sherardised cast iron. Covers the same cable diameters as the SK11–SK31 range:
| SK11 (stainless) | 6 – 11 mm |
| SK21 (stainless) | 12 – 23 mm |
| SK31 (stainless) | 17 – 31 mm |
Larger diameters (up to 100 mm+) are available as a custom order. Contact us with your cable diameter for a quote and lead time. Body dimensions (width, jaw depth, bracket slot, bolt size) differ from the cast-iron SK range shown on our Shaft Cable Clamps page, since this is a thinner-profile design. Confirm dimensions with us before ordering if you're matching an existing bracket.
Need a replacement part instead of a full unit? Browse Spare Parts →
Frequently Asked Questions
What's the difference between this and your standard SK shaft cable clamps?
The standard SK range is SG 42 cast iron with ArmorGalv® Sherardising, built for high shaft loads. The 316 range uses the same self-tightening two-piece design in an ultra-thin body. Stainless lets us drop wall thickness for cheaper international transport. Unit price is higher. Coating maintenance is not the comparison. Load capacity and body dimensions are different, so treat them as two products and confirm the fit.
What sizes are available?
SK11, SK21 and SK31 equivalents, covering cable diameters from 6 mm to 31 mm. Larger diameters up to 100 mm+ are available as a custom order. Contact us with your cable diameter and we'll confirm size, pricing and lead time.
Has it been tested?
Yes, compression strength up to 71 kN has been tested. The design is ISO 9001 compliant.
Can the clamps be reused?
Yes, the design is quick-release and fully reusable, which reduces long-term replacement cost compared to single-use clamps.
Where is it manufactured?
Johannesburg, South Africa, by STOTKO Engineering since 1973.
What if I need a size outside the SK11–SK31 range?
Contact us with your cable diameter: custom sizes up to 100 mm+ are available; larger runs need a lead time so give us a call for confirmation.
